CASEMENT SYSTEMS
The Aluminum Hinged System is a versatile and durable solution designed for doors and windows that open on hinges. Known for its strength, thermal insulation, and aesthetic appeal, it is ideal for residential and commercial applications requiring inward or outward opening mechanisms.
Key Features:
Strong and durable profiles for long-lasting performance
Thermal break options for improved energy efficiency
Compatible with double or triple glazing
Smooth opening and closing with high-quality hinges
Suitable for large openings while maintaining airtightness
ZL 45
SYSTEM DESCRIPTION
Thermal brake: Not available
Glass thickness: Single glass is 6mm
Double glass 6+6 mm
Glass brand : Turkish SISE cam Saint Gobin- Guardain - Emirates float glass
Accessories Origin: Turkish
Rubber Type: EPDM by high resistance to heat for a long time.
Connection method : SCREW
ZL 60
SYSTEM DESCRIPTION
Section Origin: Turkish
Thermal brake: Not available
Glass thickness: Single glass is 10mm
Double glass 6+6 mm
Glass brand : Turkish- sise cam -Saint Gobin- Guardain - Emirates float glass
Accessories Origin: Italian
Rubber Type: EPDM by high resistance to heat for a long time.
Connection method : Crimping
ZL 84
SYSTEM DESCRIPTION
Various opening options in doors and windows,
Safe air and water drainage system,
Different shapes and with different static values, aesthetic and stable solutions with mullion profiles,
Technical Properties :
Frame Depth 84 mm
Sash Depth 93,5 mm
Wall Thickness 1,8 mm
Glass Thickness 28 - 68 mm
Thermal Insulation 42 mm
Performances :
Thermal Insulation - EN ISO 10077-2 Uf = 1,90 W/m2K
Watertightness - EN12008:1999-11 E1200
Air Permeabilitiy - EN12207:2016-12 Class 4
Resistance to wind load - EN12210:2016-03 Class C4/B4
BF 77
SYSTEM DESCRIPTION
Sash height can rich to 3.5 meters.
different visual variation for sashes.
Sashes are carrying by lower pulleys.
Basic and master locks are available.
It can be applied in various variations up to 7 sashes.
45 and 90 degree frame montage alternative.
Press and mechanical corner joint options for frame and sash.
Sash width can rich to 1.2 meters.
Technical Properties :
Frame Depth : 77
Sash Depth : 77
Wall Thickness : 1.8 mm
Glass Thickness : 14 - 50 mm
Thermal Insulation : 24 - 32 mm
Performances :
Thermal Insulation - EN ISO 10077-2 Uf = 2,947 W/m2K
GUTMANN GWD 070
SYSTEM DESCRIPTION
Symmetrical, stabilizer construction with identical corner and T-connectors.
chamber coaxial hollow chamber with a central seal, glass rebated insulation inserts, and a 9 mm thick outer glass system gasket to improve the thermal insulation of the frame (HW = highly thermally insulated).
Surface-mounted fittings for wing weights of up to 300 kg; concealed fittings for up to 180 kg.
Use of glass up to 55 mm in the sash and 45 mm in the fixed field.
Sound insulation up to 47 dB (SK 5).
Burglary protection RC1 N, RC2, and RC3 according to DIN EN 1627.
View width from 98 mm for tilt-and-turn windows.
Euronet for free find
GUTMANN SC89
SYSTEM DESCRIPTION
Profile depth: Frame 98 mm | sash 35 mm
Sash sizes up to 2200 mm width and height up to 2200 mm
Sash weights up to 150 kg
Panel thicknesses up to 32 mm
Symmetrical profi le design for uniform accessory parts in the inner and outer shell
Straightforward seal of the meeting stiles using a simple sealing system
Simple installation of sash elements
Applications
Residential Buildings – Bedrooms, living rooms, and kitchens for ventilation and light.
Commercial Projects – Offices, schools, and hospitals for efficient air circulation and energy savings.
High-Rise Buildings – Provides safety and effective sealing against wind and noise.
